Heat Pumps
The ideal heating and cooling solution for mild climates
Heat Pumps
The ideal heating and cooling solution for mild climates
RunTru heat pumps offer a practical and cost-effective solution for your home comfort needs. Not only will these efficient and durable units keep your home comfortable year-round, they’ll do it without breaking your budget.

E4HL5 Low Profile Heat Pump
- 15.2 SEER2
- 8.1 HSPF2
- 1.5 – 5 ton capacity
- 24V Inverter
- Compact design for small installation footprints
- Tier 1 CEE Certified (North & Canada)
- Quiet operation (67db)
E4HL5 Low Profile Heat Pump
E4HL5 Low Profile Heat Pump
Model | Capacity (Tons) | Vapor Line | Dimensions (in) | ||
H | W | D | |||
E4HL5018A1000A | 1.5 | 3/4″ | 31.6 | 35.8 | 14.1 |
E4HL5024A1000A | 2 | 3/4″ | 31.6 | 35.8 | 14.1 |
E4HL5030A1000A | 2.5 | 3/4″ | 31.6 | 35.8 | 14.1 |
E4HL5036A1000A | 3 | 3/4″ | 31.6 | 35.8 | 14.1 |
E4HL5042A1000A | 3.5 | 7/8″ | 52.4 | 37.4 | 14.4 |
E4HL5048A1000A | 4 | 7/8″ | 52.4 | 37.4 | 14.4 |
E4HL5060A1000A | 5 | 7/8″ | 52.4 | 37.4 | 14.4 |
RunTru Limited Warranty:
5-year limited warranty for functional parts
10-year warranty for functional parts with registration
20-year warranty for heat exchanger
Find out more about the RunTru Limited Warranty here.
Energy and Owner Guides
Contractor Resources
Technical Documents

A4HP4 Heat Pump
- 14.3 SEER2
- 1.5 – 5 ton capacity
- All-aluminum coil
- Scroll compressor
- Quiet operation (76db)
- Smaller size options for tighter spaces
- Pre-painted steel cabinet and base pan
- Assembled in Tyler, Texas
A4HP4 Heat Pump
A4HP4 14.3 SEER2 Heat Pumps*
Model | Capacity (Tons) | Vapor Line | Dimensions (in) | ||
H | W | D | |||
A4HP4018D1000A | 1.5 | 3/4″ | 32.6 | 29.8 | 29.8 |
A4HP4024D1000A | 2 | 3/4″ | 32.6 | 29.8 | 29.8 |
A4HP4030D1000A | 2.5 | 3/4″ | 28.6 | 29.8 | 29.8 |
A4HP4036D1000A | 3 | 7.8″ | 36.6 | 34.3 | 34.3 |
A4HP4042D1000A | 3.5 | 7/8″ | 44.6 | 34.3 | 34.3 |
A4HP4048D1000A | 4 | 7/8″ | 44.6 | 34.3 | 34.3 |
A4HP4060D1000A | 5 | 7/8″ | 44.6 | 34.3 | 34.3 |
*This product is rated as SEER2 to align with the 2023 Department of Energy regulations.
All models feature 3/8″ liquid line.
SEER2, or Seasonal Energy Efficiency Ratio, measures how efficiently a unit can cool your home in the summer. The higher the SEER2 number, the less energy you’ll use.
RunTru Limited Warranty:
5-year limited warranty for functional parts
10-year warranty for functional parts with registration
20-year warranty for heat exchanger
Find out more about the RunTru Limited Warranty here.
Energy and Owner Guides
876.37 KB
875.35 KB
877.90 KB
873.99 KB
877.58 KB
878.21 KB
877.03 KB
877.15 KB
875.71 KB
Contractor Resources
Technical Documents

A4HP5 Heat Pump
- 15.2 SEER2
- 1.5 – 5 ton capacity
- All-aluminum coil
- Scroll compressor
- Quiet operation (76db)
- Smaller size options for tighter spaces
- Pre-painted steel cabinet and base pan
- Assembled in Tyler, Texas
A4HP5 Heat Pump
A4HP5 15.2 SEER2 Heat Pumps*
Model | Capacity (Tons) | Vapor Line | Dimensions (in) | ||
H | W | D | |||
A4HP5018D1000A | 1.5 | 3/4″ | 32.6 | 29.8 | 29.8 |
A4HP5024D1000A | 2 | 3/4″ | 32.6 | 29.8 | 29.8 |
A4HP5030D1000A | 2.5 | 3/4″ | 28.6 | 29.8 | 29.8 |
A4HP5036D1000A | 3 | 3/4″ | 36.6 | 34.3 | 34.3 |
A4HP5042D1000A | 3.5 | 7/8″ | 44.6 | 34.3 | 34.3 |
A4HP5048D1000A | 4 | 7/8″ | 44.6 | 34.3 | 34.3 |
A4HP5060D1000A | 5 | 7/8″ | 44.6 | 34.3 | 34.3 |
*This product is rated as SEER2 to align with the 2023 Department of Energy regulations.
All models feature 3/8″ liquid line.
SEER2, or Seasonal Energy Efficiency Ratio, measures how efficiently a unit can cool your home in the summer. The higher the SEER2 number, the less energy you’ll use.
RunTru Limited Warranty:
5-year limited warranty for functional parts
10-year warranty for functional parts with registration
20-year warranty for heat exchanger
Find out more about the RunTru Limited Warranty here.
